well again i got bored today and desided to reinstall all my nitrous stuff and add onto it..so it'll match the new setup when i get the motor back an will be ready to go "Plug And Play type deal"anyway i hooked up some switch's for my WOT switch Bottle heater's and all my little L.E.D's that i have set up as warning lights when the bottles get to hot and when the systems armed and so forth anyway onto the pictures!:rock: :rock:
Took Apart the dash!

Neatly laied parts on grass lol

Switch's put into place

All wired up and ready to go into the truck

Back in the truck

Heres some of the Leds working "Blue Is for nitrous Arm'd" An the red Would Be the Bottle Warmers

WOT Switch

Warning Light For Bottle Heaters When the Pressure gets to high the pressure switch shuts off and kicks this light on

Purge Button very Top Of A Piller

Finished Product!

Tommorow Will Be Working on Blow Down Tubes and more fun stuff!

this is around the 30th or 40th Nitrous Install i'v done what do you think?
