Not bad at all. There are 4 phillips head screws you take out of the door panel.Prof said:How difficult was the Cal Vue install?
Just pot and unplug?
One by the mirror, 1 by the open handle and 2 at the bottom edge front & back.
You don't even have to totally remove it just lift it a little and it gives you clearance to the nuts you need to loosen.
There are 3 10mm nuts that hold the mirror on.
Remove those and the last thing you need to do unplug the wire harness and where the socket part that stays with the mirror has a catch on either side that needs to be released before the mirror will come loose.
Hang onto the mirror and use a screwdriver to unhook it and it will fall free.
Installation is in reverse order.
I'll get some pictures a little later.
